2.0MP IP Webcam Camera from China manufacturer - Shenzhen Clairvoyance Intellect Electronic Co.,Ltd

Payment Terms:	WU;Pay Pal
Place of Origin:	Guangdong, China (Mainland)

Product Detail

Model No.: QLM-FIPD125

Packing: Cartons

Brand Name: QLM

Compression Mode: H.264

Max. Pixel: 5.0MP

Leds: 42*F5 LEDs

Frame Rate: 5.0MP@10fps,3.0MP@17fps,108...

Power input: DC 12V +5%

Production Capacity: 6000pcs/month

Delivery Date: samples 3-5days Quantity...

Customerized: Yes

Sensor: 1/2.5'' Progressive Scan CM...

Onvif: Onvif 2.0

IR View: 20-25m

Network Protocol: TCP/IP/HTTP/RTSP/FTP/PPPOE/...

This Mini camera Max. Pixel is 5MP, and have 42F5 LEDS, IR View is 20-25m.

Feature:

1. Standard H.264 compression 2.0MP IP Webcam Camera

2. 1/2.5'' 5.0Megapixel CMOS sensor

3. 5.0MP@10fps,3.0MP@17fps,1080P@25fps video frame rate.

4. Multipleadjustable resolution with self-adapting technology

5. Supportingdual streaming level

6. Protocol-TCP/IP/HTTP/RTSP/FTP/PPPOE/DDNS/NTP/UPnP etc.

7. Remote viewand management by IE and client software (CMS with 64CH).

8. USB memoryoptional (Only for original Kingston)

9. Support ONVIF2.0

Specification:

Itemno.	QLM-FIPD125 2.0MP IP Webcam Camera
Image Sensor	1/2.5'' 5.0 Megapixel Progressive Scan CMOS sensor
Lens	3.6mm fixed lens
LEDs& IR distance	42*F5LEDs, 20-25m IR view
Min.Illumination	1.76V/Lux-sec;0Lux@IR on
CPU	TITMS320DM368
OS	EmbeddedRTOS design, dual core DSP 32bit.
Video Codec	H.264
Analog Video Output	1CHBNC output, support CVBS standard
Video Resolution	Mainstream: 5MP@10FPS; 3MP@15FPS; 1080P, 1200P, 1024P, 960P,720P@25FPS
Video Resolution	Substream: 640360, 480270, 352*192@25FPS
Video Frame Rate	25FPS,support adjustable 1-25fps
Streaming Level	2adjustable
BitRate	50k-8Mbps
Audio compression	AACstandard, Support 2-way audio and Synchronous AV
Audio input	2Vp-p,1Vms, support pickups input (only for active audio)
Audio output	16Vms,30mw, support earphone or power amplifier
Network Port	10-100MEthernet RJ45 port
USB Port	1USB port, support max.64G U disk recording
Network Protocol	TCP/IP/HTTP/RTSP/FTP/PPPOE/DDNS/NTP/UPnP
PTZ Control	RS422/RS485Serial Port. , support multiple PTZ control protocol, such as PELCO (P) / PELCO(D) / MOLYN (P) / SANTA (P)
Software	FreeClient software and charged Intelligent Video CMS software
Software	IVSsoftware support mobile phone view. Symbian, Android and IPhone mobile.
ONVIF	ONVIF2.0 compliant
Working Temperature	temperature-10 ~ +50 C
Power input	DC12V +5%
